Basic Info.
| Model NO. | DS-6LS |
| Processing Accessory | Chuck CNC Lathe |
| Guide Rail | Inclined Guide Rail |
| Tool Holder | Single-tool Holder CNC Lathe |
| Power Source | Hydraulic Pressure |
| Controlling Mode | CNC |
| Automatic Grade | Automatic |
| Setting Mode | Floor-type |
| Precision | High Precision |
| Certification | GS, CE, ISO 9001 |
| Condition | New |
| After-Sales Service Provided | Online Support |
| Spindle Speed | 0-4500 Rpm |
| Color | Customers Custom-Made |
| Weight (Kg) | 2900 |
| Brand Name | Das Own Brand |
| Spindle Nose | A2-5(6 Inch) |
| X/Z Axis Travel | 1030/300 |
| Model | Ds-6ls |
| Machine Type | Slant Bed CNC Lathe |
| After-Servies Provided | 1 Year Warrenty |
| Dimension(L*W*H) | 2400*1500*1950 |
| Application | Material Processing |
| Name | Gang Type CNC Lathe with Millings |
| Repeatability (X/Y/Z) (mm) | 0.005 |
| CNC or Not | CNC |
| Transport Package | Wooden Box Package |
| Specification | 2400*1500*1950 |
| Trademark | DAS |
| Origin | China |
| HS Code | 8458110090 |
| Production Capacity | 20 Sets/Month |
Product Description
DAS DS-5/6LS Long Travel Torno CNC High Precision Metal Automatic Slant Bed cnc lathe with side millings
Product Description
- Machine tool control system uses Taiwan SYNTEC 6TA-T3S system. Other company's numeral control system can also be used when user requires so.
- Machine body is cast in one piece with resin bonded sand, so it features strong vibration resistance and less deformation. The lathe bed tilts by 45° and the inclined placement of lathe carriage and tool holder will result in easy operation and chip removal. The machine tool has pleasant design appearance and less space occupation.
- Equipped with computer automatic lubrication system for the linear guide and ball screw forced lubrication, ensure that the guide rail and the service life of screw.
| Name | DS-5LS | DS-6LS |
| Adjacent tool change time (s) | 0.3 | |
| Tool change style | Random | |
| Square knife knife holder (mm) | 20X20 | |
| Round hole knife holder (mm) | φ20 | |
| With chuck size | 5 Inch | 6 Inch |
| Spindle speed (r/min) | 1-4500 | |
| Spindle bore (mm) | φ46 | φ56 |
| Center height (mm) | 56 | |
| The maximum diameter of rotation (mm) | 380 | |
| Spindle motor power (KW) | 5.5 | 7.5 |
| Minimum system Resolution | 0.001 | |
| X/Z Axis stroke (mm) | 1030/300 | |
| X/Z axis fast moving speed (m/min) | 30 | |
| X/Z axis Repetitive positioning accuracy (mm) | ±0.003 | |
| Taper (mm) | ≤0.003/100 | |
| Card position size (mm) | ≤0.003 | |
| X servo-motor (KW) | 1.31.3 | |
| Z servo-motor (KW) | ||
| Hydraulic station (KW) | 0.75 | |
| Water tank motor power (KW) | 150W | |
| Cooling water tank capacity (L) | 60 | |
| Bar feeder center height (mm) | 1120 | |
| Weight (KG) | 2800 | 2900 |
| Size (L*W*H mm) | 2250x1500x1950 | |
| Power (KW) | 13 | 15 |
Good Feedback
Foshan Shunde Guoqiang Daosheng Industrial Co., Ltd. is located in Chencun, the important machinery town in Shunde District,Foshan. Sticking to the human-centering management, we are in possession of a group of highly competent technical personnel, a market oriented experienced sales team. In the gesture of sincere cooperation, we strive to establish a promise keeping and quality . Our major products include CNC series gang tool type lathes , turret lathes, take heart-type lathes and milling-type lathes,featuring space saving, low cost and diversified arrangement etc.They can also meet the demand for precise processing of different products. The products find widespread application in the manufacture of cars, motorcycles and accessories thereof,electronic industry, optical instruments, clocks and watches as well as special motors etc. We have precise lathe equipment, complete quality guarantee system, prompt goods supply as well as perfect after-sales service,which ensure us the first consideration when you purchase high-precision machine tools.
